Ships within 25 days
View
View
View
View
| Type of Product | Round Waterproof Connector |
| Model No | XS2R-D426-G10-F |
| Type | For DC |
| Rated Voltage (V) | DC 250 |
Type of Product |
Round Waterproof Connector |
Model No |
XS2R-D426-G10-F |
Type |
For DC |
Rated Voltage (V) |
DC 250 |
Monotaro ID |
39107302 |
No. of Pole |
4 |
Color |
(Contact block) Light gray |
Material (Contact Block) |
PA resin (UL94V-0) |
Protection Class |
IP67(IEC529) |
Material (O-ring) |
Rubber |
Material (fixing bracket) |
Brass / Ni plating |
Cable Length (m) |
5 |
Connector |
One side connector |
Country of Origin |
JAPAN |
Operating Temperature Range |
-25 to +70℃ |
Import Country |
Direct Import from Japan |
Cable |
With cable |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Fixing Type |
M12 screw type |
Withstand voltage (V / min) |
AC1500 (leakage current 1 mA or less) (connector part) |
Cable Holding Strength (N/15s) |
Cable outer diameter: (Φ6mm) 98, (Φ4-5mm) 49, (Φ3mm) 29 |
Ambient Humidity (% RH) |
20 to 85 |
Insulation Resistance (MOhm) |
10³ Or More (At 500 V DC) |
Contact Resistance (ohm) |
40 mΩ or Less (20 mV mΩ or Less, 100 mA mΩ or Less) (Connector) |
Gold Plated (μm) |
0.4 |
