| Type of Product | Round Waterproof Connector |
| Model No | XS3F-S421-405-R |
| Withstand Voltage | Connector: AC1000V 1min (Leakage current 1 mA or less) |
| Type | Waterproof connector |
Type of Product |
Round Waterproof Connector |
Model No |
XS3F-S421-405-R |
Withstand Voltage |
Connector: AC1000V 1min (Leakage current 1 mA or less) |
Type |
Waterproof connector |
Rated Voltage (V) |
DC 125 |
Monotaro ID |
46683971 |
Rated Current (A) |
1 |
No. of Pole |
4 Pole |
Surface Treatment |
Fixing tool: Nickel plating |
Contact Material |
Phosphor bronze / nickel base gold plating |
Shape |
Straight |
Cover Material |
Thermoplastic elastomer |
Protection Class |
IP67(IEC529) |
Material (O-ring) |
Rubber |
Cable Length (m) |
5 |
Country of Origin |
JAPAN |
Operating Temperature Range |
0 to +70℃ |
Import Country |
Direct Import from Japan |
Cable |
Robot cable |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Fixing Type |
Snap-in type |
Tensile Strength |
Cable: 49N / 15s |
Installation |
S8 type |
Insulation Resistance (MOhm) |
10³ Or More (At 500 V DC) |
Contact Resistance (ohm) |
Connector: 40 mΩ or less (DC 20 mV mΩ or less, 100 mA or less) |
