| Type of Product | Discrete Wire IDC Connector |
| Total Insertion Force | 16x1.96N or less |
| Withstand Voltage | 500 VAC, 1 min (leakage current 1 mA or less) |
| Type | Polarity guide type |
Type of Product |
Discrete Wire IDC Connector |
Total Insertion Force |
16x1.96N or less |
Withstand Voltage |
500 VAC, 1 min (leakage current 1 mA or less) |
Type |
Polarity guide type |
Rated Voltage (V) |
AC300 |
Monotaro ID |
8593611 |
Rated Current (A) |
AWG24：3 |
Standard |
UL standard (file No. E103202) certified RoHS compliant |
No. of Pole |
16-Pole |
Housing Material |
Glass-filled PBT resin (UL94V-0) / Black |
Suitable Wire |
AWG24 (using UL-1061), wire outer diameter: Φ1.1 to 1.3 mm, core wire configuration: 7 stranded wires |
Insertion / Removal Durability (Times) |
50 |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Part No |
64-3394-38 |
Dimension A (Φmm) |
φ24.9 mm |
Manufacturer Part Number |
XG5M-1632-N |
Insulation Resistance (MOhm) |
10³ or more (at 500 VDC) |
Polarity Guide |
1 |
Spark Plug Type |
Type XG4A (flat cable connector long lock), type XG4A (flat cable connector lock lever rear mounting), type XG4A (flat cable connector two-tier stacking), type XG4E (flat cable connector pressure welding type plug long lock), type XG4C (flat) Cable connector box type plug), XG8W / XG8B (2 rows of original plugs), XG4A / XG4C should use the same number of polar slots as the number of polar guides of XG5M-N. |
Contact No. |
1 |
Operation Ambient Temperature (°C) |
-55 to +85 (no freezing at low temperatures) |
Single Removal Force |
0.29 N or more (with □ 0.64mm test gauge) |
Contact Resistance (ohm) |
20 or less (20mV or less, 100mA or less) |
Dimension B (Φmm) |
φ17.78 mm |
