| Type of Product | Half Pitch Connector |
| Model No | XH2B-0141-A |
| Total Insertion Force | Number of poles x 0.78 N or less |
| Type | Plug |
Type of Product |
Half Pitch Connector |
Model No |
XH2B-0141-A |
Total Insertion Force |
Number of poles x 0.78 N or less |
Type |
Plug |
Rated Voltage (V) |
AC 125 |
Total Removal Force |
Number of poles x 0.10 N or more |
Monotaro ID |
46632101 |
Rated Current (A) |
0.5 |
Standard |
RoHS directive, UL standard (File No.E103202) |
No. of Pole |
100 Pole |
Insertion / Removal Durability (Times) |
400 |
Country of Origin |
JAPAN |
Import Country |
Direct Import from Japan |
Terminal Shape |
Dip L-type terminal with locking pin |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Part No |
64-3397-56 |
Withstand voltage (V / min) |
AC650, 1 (leakage current 1 mA or less) |
Dimension A (Φmm) |
76.2 |
Insulation Resistance (MOhm) |
10³ Or More (At 500 V DC) |
Operation Ambient Temperature (°C) |
-55 to +105 (no freezing at low temperatures) |
Contact Resistance (ohm) |
30 mΩ or less (20 mV mΩ or less, 100 mA or less) Combination of XH2A-@@42 and XH2B-@@41 |
Dimension B (Φmm) |
69.85 |
Dimension C |
66.6 mm |
Dimension d |
62.23 mm |
