| Type of Product | D-Sub Connector Plug Dip L-Shaped Terminal |
| Model No | XM3C-3722-111 |
| Rated Voltage (V) | AC 300 |
| Monotaro ID | 46590363 |
Type of Product |
D-Sub Connector Plug Dip L-Shaped Terminal |
Model No |
XM3C-3722-111 |
Rated Voltage (V) |
AC 300 |
Monotaro ID |
46590363 |
Rated Current (A) |
3 |
No. of Pole |
37 |
Housing Material |
PBT resin (UL94V-0) / black |
Contact Material |
(Contact area) Phosphor bronze/nickel base, gold plating (Terminal area) Phosphor bronze/nickel base, tin plating |
Shape |
Plug |
Material (Shell) / Finish |
Steel |
Insertion / Removal Durability (Times) |
200 |
Country of Origin |
CHINA |
Operating Temperature Range |
-55 to +105 ℃ (no freezing at low temperatures) |
Import Country |
Direct Import from Japan |
Terminal Shape |
DIP L-shaped terminal |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Withstand voltage (V / min) |
AC 1000 (leakage current 1 mA or less) |
Insulation Resistance (MOhm) |
10³ Or More (At 500 V DC) |
Contact Resistance (ohm) |
15 mΩ or Less (20 mV mΩ or Less, 100 mA mΩ or Less) |
Specifications |
Millimeter screw M2.6 x 0.45 |
Fixture Type |
With fixture 2 |
Ground Metal Bracket |
Tap hole grounding bracket |
Processing |
Nickel plating |
