| Type of Product | D-Sub Connector Socket |
| Model No | XM3B-2522-131 |
| Withstand Voltage | 1000 V AC, 1 min (leakage current 1 mA or less) |
| Rated Voltage (V) | AC 300 |
Type of Product |
D-Sub Connector Socket |
Model No |
XM3B-2522-131 |
Withstand Voltage |
1000 V AC, 1 min (leakage current 1 mA or less) |
Rated Voltage (V) |
AC 300 |
Monotaro ID |
46589742 |
Rated Current (A) |
5 |
Standard |
RoHS directive |
No. of Pole |
25 |
Housing Material |
Glass-filled PBT resin (UL94V-0) / Black |
Shape |
Socket Dip L-type terminal |
Series |
XM3B Series |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Included Components |
Fixture (shape XM2Z-0013 (inch screw # 4-40UNC)), tap hole ground metal fittings |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Terminal Type |
L-Shaped Terminal |
Material (Contact Connection Part) |
Phosphor bronze |
Dimension A (Φmm) |
53 |
Insulation Resistance (MOhm) |
10³ Or More (At 500 V DC) |
Operation Ambient Temperature (°C) |
-55 to +105 (no freezing in the bass) |
Contact Resistance (ohm) |
15 mΩ or Less (20 mV mΩ or Less, 100 mA mΩ or Less) |
Dimension B (Φmm) |
47.04 |
Dimension C |
38.35 mm |
Dimension d |
33.12 mm |
Dimension F (Φmm) |
2.76 |
Dimension E (Φmm) |
30.36 mm |
