Ships within 19 days
Model No
No. of Pole
View
View
View
View
| Type of Product | Simple Connector For Industrial Equipment |
| Model No | XN2A-1570 |
| Withstand Voltage | 1000 V AC, 60 seconds (leakage current 1 mA or less) |
| Type | Plug Connector For Cable Connection |
Type of Product |
Simple Connector For Industrial Equipment |
Model No |
XN2A-1570 |
Withstand Voltage |
1000 V AC, 60 seconds (leakage current 1 mA or less) |
Type |
Plug Connector For Cable Connection |
Rated Voltage (V) |
DC 32 |
Monotaro ID |
39105437 |
Rated Current (A) |
3 / pole (when using AWG20 wire), 2 / pole (when using AWG22 wire), 1 / pole (when using AWG24 wire), 0.5 / pole (when using AWG26 or 28 wire) |
Standard |
RoHS directive |
No. of Pole |
5 |
Contact Material |
Contact part: Copper alloy / Nickel base gold plating (0.2 μm) Connection part: Copper alloy / Nickel base tin plating Terminal part: Copper alloy / Nickel base tin plating |
Suitable Wire |
0.08mm² (AWG28) to 0.5mm² (AWG20) However, the outer diameter of the wire coating must be Φ1.5 or less. |
Body Material |
PBT resin (UL94V-0) / black |
Insertion / Removal Durability (Times) |
50 |
Cover Material |
PBT resin (UL94V-0) / black |
Lever Material |
PA resin (UL94V-0) / Natural (white) |
Material (Foot Plate) |
PC resin (UL94V-0) / transparent |
Spring Material |
stainless steel |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Insulation Resistance (MOhm) |
1000 or more (at 500 V DC) |
Operation Ambient Temperature (°C) |
-30 to +75 |
Contact Resistance (ohm) |
30 mΩ or Less (20 V DC mΩ or Less, 100 mA mΩ or Less) |
