| Type of Product | Half Pitch Connector |
| Model No | XH4A-5035-A |
| Total Insertion Force | Number of poles x 1.47 N or less |
| Rated Voltage (V) | AC 125 |
Type of Product |
Half Pitch Connector |
Model No |
XH4A-5035-A |
Total Insertion Force |
Number of poles x 1.47 N or less |
Rated Voltage (V) |
AC 125 |
Total Removal Force |
Number of poles x 0.15 N or more |
Monotaro ID |
46631611 |
Rated Current (A) |
0.5 |
Standard |
RoHS directive, UL standard (File No.E103202) |
No. of Pole |
50 Pole |
Housing Material |
PPS resin with glass (UL94V-0) / Black |
Contact Material |
(Contact part) Phosphor bronze / nickel base Gold plating (0.15 μm), (Terminal part) Phosphor bronze / nickel base Gold flash plating |
Insertion / Removal Durability (Times) |
50 |
Country of Origin |
JAPAN |
Import Country |
Direct Import from Japan |
Terminal Shape |
With dip straight terminal and stop pin (standard type) |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Pin Material |
Phosphor bronze / tin plating |
Part No |
64-3399-47 |
Withstand voltage (V / min) |
AC650, 1 (leakage current 1 mA or less) |
Dimension A (Φmm) |
39.08 |
Insulation Resistance (MOhm) |
10³ Or More (At 500 V DC) |
Operation Ambient Temperature (°C) |
-55 to +105 (no freezing at low temperatures) |
Contact Resistance (ohm) |
30 mΩ or less (At 20 Mv mΩ or less, 100 mA or less) Depends On Mating Between Xh4A-@@31 Units |
Dimension B (Φmm) |
30.48 |
Dimension C |
34.98 mm |
Locator Material |
Glass-filled PBT resin (UL94V-0) / Black |
