| Type of Product | Round Waterproof Connector |
| Model No | XS5C-D4C6 |
| Type | Socket |
| Rated Voltage (V) | DC 250 |
Type of Product |
Round Waterproof Connector |
Model No |
XS5C-D4C6 |
Type |
Socket |
Rated Voltage (V) |
DC 250 |
Monotaro ID |
46680094 |
Rated Current (A) |
4 |
No. of Pole |
4 |
Contact Material |
Brass / Ni base gold plating 0.4 μm |
Connection Type |
Crimping |
Shape |
L type |
Lock Operation Force (N ・ M) |
0.1 to 0.25 |
Withstand voltage (V) |
(Connector part) AC 1500 + 1 minute (leakage current 1 mA or less) |
Material (Contact Block) |
PBT resin (UL94V-0) |
Lock Strength |
Tensile: 100N / 15s, rotation: 1N ・ m / 15s |
Cover Material |
PBT resin (UL94V-0) |
Protection Class |
IP67(IEC60529) |
Material (O-ring) |
Rubber |
Material (fixing bracket) |
Zinc alloy / Ni plating |
Country of Origin |
JAPAN |
Operating Temperature Range |
-25 to +70℃ |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Cable Holding Strength (N/15s) |
100 (when the cable diameter is Φ3 mm) |
Insulation Resistance (MOhm) |
1000 or more (at 500 V DC) |
Contact Resistance (ohm) |
(Connector part) 40 mΩ or Less (20 mV mΩ or Less, 100 mA mΩ or Less) |
Suitable Cable Outer Dia. (Φmm) |
For Φ3 (Φ3 to Φ4) |
