Ships within 15 days
View
View
View
View
| Type of Product | Plug |
| Model No | 5083117 |
| Type | C |
| Contact Resistance | 15 mΩ |
Type of Product |
Plug |
Model No |
5083117 |
Type |
C |
Contact Resistance |
15 mΩ |
Housing Material |
PS |
Contact Material |
Brass |
Pitch |
2.54 mm |
Gender |
Male |
Mounting Type |
Through Hole |
Current Rating |
2 A |
Country of Origin |
Germany |
Contact Plating |
Gold over Nickel |
Orientation |
Right Angle |
No. of Contacts |
96 |
Termination Method |
Solder |
Maximum Operating Temperature |
+125°C |
Minimum Operating Temperature |
-65°C |
No. of Row |
3 |
Rating |
C1 |
Row Loading |
a/b/c |
Name of Manufacturer/Packer/Importer |
RS Component |
