| Type of Product | Conversion Connector |
| Model No | NJ-SMAP-18G |
| Type | Conversion connector |
| RoHS Directive | Correspondence |
Type of Product |
Conversion Connector |
Model No |
NJ-SMAP-18G |
Type |
Conversion connector |
RoHS Directive |
Correspondence |
Rated Voltage (V) |
AC 500 |
Monotaro ID |
50521328 |
Contact Material |
(Center) Beryllium copper / gold plating, (External) Brass / nickel plating |
Country of Origin |
Japan |
Operating Temperature Range |
-40 to +85 |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Tocone |
Adapter Type |
Type N-SMA |
Insulation Resistance (MOhm) |
3 or less |
Characteristic impedance (Ω) |
50 |
Cutting Shape |
Jack plug |
Voltage standing wave ratio |
1.15 or less (DC to 9GHz), 1.2 or less (9 to 15GHz), 1.3 or less (15 to 18GHz) |
Frequency Used (GHz) |
18 |
