Ships within 19 days
Rated Voltage (V)
Model No
View
View
View
View
| Coil Resistance | 237 Ω |
| Model No | G6KU-2F-RF-DC5V |
| Voltage | [Contact] AC125 / DC30 V |
| Type of Product | Surface Mount High Frequency Relay |
Coil Resistance |
237 Ω |
Model No |
G6KU-2F-RF-DC5V |
Voltage |
[Contact] AC125 / DC30 V |
Type of Product |
Surface Mount High Frequency Relay |
Terminal Shape |
External L-Shaped Surface Mount Terminal |
Rated Voltage (V) |
DC5 |
Monotaro ID |
40800604 |
Country of Origin |
Japan |
Operating Time (ms) |
3 ms or less (Actual Value Approx. 1.2 ms) |
Maximum Contact Voltage (V) |
AC125 V / DC60 V |
Power Consumption (mW) |
About 100 mW |
Contact Resistance |
100 mΩ |
Rated Carrying Current (A) |
1 A |
Coil Voltage |
DC5 V |
Import Country |
Direct Import from Japan |
Operating Time |
Maximum: 1 GHz |
Contact |
Insertion Loss: 0.2 dB or less, Isolation Contact: 20 dB or more, Between Different Poles: 30 dB or more |
Height (mm) |
5.4 mm |
Contact Configuration |
2C |
Type of Sign |
Board Mounting |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Structure |
Plastic Seal Type |
Looking for bulk pricing or different specifications?
