Ships within 19 days
Model No
View
View
View
View
| Model No | G6K-2P DC24 |
| Shock Resistance | 1000m/s² |
| Type of Product | Surface Mount Relay |
| Series | G6K Series |
Model No |
G6K-2P DC24 |
Shock Resistance |
1000m/s² |
Type of Product |
Surface Mount Relay |
Series |
G6K Series |
Type |
Printed circuit board relays |
Terminal Shape |
Terminals for printed circuit boards |
Rated Voltage (V) |
DC24 |
Monotaro ID |
39069335 |
Country of Origin |
Japan |
Mass (g) |
About 0.7 |
Mechanical Durability |
50 million times (opening and closing frequency 36,000 times / h) |
Ambient Humidity to Use |
5 to 85%RH |
Electrical Durability |
100,000 times or more (rated load switching frequency 1800 times / h) |
No. of Pole |
2-pole |
Standard |
Not compatible with UL, CSA standard, Telcordia standard |
Import Country |
Direct Import from Japan |
Contact Configuration |
2C |
Vibration Resistance (Malfunction) |
10 to 55 to 10 Hz, single amplitude 1.65 mm (double amplitude 3.3 mm), 55 to 500 Hz 200 m / s² |
Shock Resistance (Malfunction) |
750m/s² |
Protection Class |
Plastic seal type |
Vibration Resistance (Destruction) |
10 to 55 to 10 Hz, single amplitude 2.5 mm (double amplitude 5 mm), 55 to 500 Hz 300 m / s² |
Pack of |
1 Pcs |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Contact Resistance (ohm) |
100 or less (DC1V 10mA voltage drop method) |
Rated Coil Voltage |
DC24 |
Specifications |
Single stable type |
Insulation Resistance (MOhm) |
1000 mohm or more (DC500 V insulation resistance meter) |
Operation Ambient Temperature (°C) |
-40 to +70 (with no icing or condensation) |
