Sungrow Double-MPPT String Inverter 7.5 kWp For 600 Vdc System, SG5.0RS-L

Name: Sungrow Double-MPPT String Inverter 7.5 kWp For 600 Vdc System, SG5.0RS-L
Brand: Sungrow
SKU: SOL.MPP.732939946
Price: 40949 INR
Availability: InStock

Visit the Sungrow Store

EMI starts at ₹3638/month. No Cost EMI available.

Max. Output Current

Model No

Explore 2 more variants

Available offers

Flat ₹300 off on Order above ₹7,000 | Valid for NEW Business Users

View

Flat ₹200 off on Order above ₹5000 | Valid for NEW Business Users

View

Flat ₹400 off on Order above ₹10,000 | Valid for REPEAT Business User

View

Flat ₹800 off on Order above ₹20,000 | Valid for REPEAT Business User

View

Features

Type of Product	Double-MPPT String Inverter
Model No	SG5.0RS-L
Protection Degree	IP65
Display	LED digital display & LED indicator

More Sungrow MPPT Solar Charge Controller products More MPPT Solar Charge Controller products

Warranty as per brand

100% Original Products

Secure payments

100% Buyer protection

Top Brands

EXPLORE OTHER VARIANTS

Ships within 7 days

SKU ID: SOL.MPP.632939956

Sungrow Double-MPPT String Inverter 9 kWp For 600 Vdc System, SG6.0RS-L

Model No

SG6.0RS-L

₹43,049

Ships within 7 days

SKU ID: SOL.MPP.432939934

Sungrow Double-MPPT String Inverter 6 kWp For 600 Vdc System, SG4.0RS-L

Model No

SG4.0RS-L

₹37,799

specifications

description

Type of Product	Double-MPPT String Inverter
Model No	SG5.0RS-L
Protection Degree	IP65
Display	LED digital display & LED indicator
Weight	10.5 Kg
Voltage Range	40 V - 560 V
Maximum Input Power	7.5 kWp
Phase	1 Phase
Dimension	445 mm x 325 mm x 150 mm
Maximum Efficiency	0.97899999999999998
Country of Origin	India
Name of Manufacturer/Packer/Importer	Sungrow India (HQ) 304,3rd Floor, Picasso Centre, Golf Course Extension Road Sector-61, Gurugram Haryana-122102
Surge Protection	DC type II / AC type II
Input Voltage	600 V
Rated Input Voltage	360 V
Ambient Temperature Range	-25 ℃ - 60 ℃
Harmonics	< 3 % (THD)
Rated Output Current	22.8 A
Maximum output power	5000 VA
Voltage Range (AC)	154 V - 276 V
Input Current	32 A (16 A / 16 A)
Cooling Method	Natural cooling
Rated Output Power	5000 W
Operating Altitude	4000 m
Mounting Method	Wall-Mounting Bracket
Topology	Transformerless
Grid Type	Grid monitoring
Function	PID Zero function
Humidity Range	0 - 100 %
Power Factor	Adjustable 0.8 leading - 0.8 lagging
Communication Function	WLAN
