| Type of Product | Multi-Function Meter |
| Measurement Range | 0.5 (Lag Power Factor), 0.5 (Lead Power Factor), 1 (Normal Power Factor), 1 - 5 (Current) A, 290 (Phase - Neutral) V ac, 45 - 65 (Frequency) Hz, 500 (Line - Line) V ac |
| Series | Alpha 20 |
| Depth | 55mm |
Type of Product |
Multi-Function Meter |
Measurement Range |
0.5 (Lag Power Factor), 0.5 (Lead Power Factor), 1 (Normal Power Factor), 1 - 5 (Current) A, 290 (Phase - Neutral) V ac, 45 - 65 (Frequency) Hz, 500 (Line - Line) V ac |
Series |
Alpha 20 |
Depth |
55mm |
Display Type |
LED |
Minimum Temperature |
-20°C |
Maximum Temperature |
+70°C |
Meter Type |
Digital |
Country of Origin |
India |
No. of Digits |
4 |
Cutout Width |
92mm |
Cutout Height |
92mm |
Name of Manufacturer/Packer/Importer |
RS PRO |
Properties Measured |
AC Current, AC Voltage, Active, Apparent Power, Frequency, Import Export Energy, Reactive |
Approvals |
IEC 60529, IEC 61010-1-2001, IEC 61326-1:2005 |
