| Type of Product | Multi-Function Meter |
| Measurement Range | 0 - 1 (Voltage V @ >10 kΩ), 0 - 10 (Voltage V @ >100 kΩ), 0 - 2 (Voltage V @ >10 kΩ), 0 - 50 (Voltage mV @ >10 kΩ) |
| Series | DI32-1 |
| Depth | 3mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Multi-Function Meter |
Measurement Range |
0 - 1 (Voltage V @ >10 kΩ), 0 - 10 (Voltage V @ >100 kΩ), 0 - 2 (Voltage V @ >10 kΩ), 0 - 50 (Voltage mV @ >10 kΩ) |
Series |
DI32-1 |
Depth |
3mm |
Display Type |
LED |
Digit Height |
10 mm |
Minimum Temperature |
-20°C |
Maximum Temperature |
+50°C |
Meter Type |
Electrical |
Country of Origin |
Germany |
No. of Digits |
4 |
Cutout Width |
45mm |
Cutout Height |
22.2mm |
Name of Manufacturer/Packer/Importer |
RS Components & Controls (I) Ltd |
Properties Measured |
Counter, Current, Frequency, Humidity, Speed, Temperature, Thermocouples, Voltage |
Approvals |
EMC 2004/108/EC, EN 61326, IEC 60529/EN 60529, UL 94 V-0 |
Manufacturer Part Number |
14110042 |
Minimum Measurement |
+80 (Thermocouple (Type B)) °C, 0 (Counter), 0 (Current mA @ 125 Ω), 0 (Frequency NPN) kHz, 0 (Frequency PNP) kHz, 0 (Frequency) kHz, 0 (Humidity) %RH, 0 (Speed) rpm, 0 (Voltage) V, -170 (Thermocouple (Type J)) °C, -200 (PT100 (3-Wire)) °C, -200 (PT1000 (2-Wire)) °C, -200 (Thermocouple (Type L)) °C, -270 (Thermocouple (Type E)) °C, -270 (Thermocouple (Type K)) °C, -270 (Thermocouple (Type N)) °C, -270 (Thermocouple (Type T)) °C, 4 (Current mA @ 125 Ω), -50 (PT100 (3-Wire)) °C, -50 (Thermocouple (Type R)) °C, -50 (Thermocouple (Type S)) °C |
