| Material | High Carbon Steel |
| Country of Origin | Japan |
| Type of Product | Needle Bearing With Three-Point Contact Ball Bearing Natb |
| Model No | NATB5905 |
Material |
High Carbon Steel |
Country of Origin |
Japan |
Type of Product |
Needle Bearing With Three-Point Contact Ball Bearing Natb |
Model No |
NATB5905 |
Rolling element material |
High Carbon Chromium Bearing Steel |
Load direction |
Radial |
Race ring shape |
Needle Roller Bearing |
Monotaro ID |
38313694 |
Inscribed Circle Diameter Fw (Φmm) |
30 |
Import Country |
Direct Import from Japan |
Outer ring type |
Flat |
JIS grade |
0 |
Shield Shape |
Open type |
Mass (g) |
136 |
Name of Manufacturer/Packer/Importer |
Nippon Thompson Co., Ltd. |
Basic Dynamic Load Rating (N) |
(Radial) 15800 (Axial) 4300 |
Basic Static Load Rating (N) |
(Radial) 22100 (Axial) 7520 |
Outer Diameter D (Φmm) |
42 |
Allowable Rotation Speed (min-1 [rpm]) |
13000 |
Width B (mm) |
25 |
Inner Diameter (mm) |
25 |
Width C (mm) |
23 |
Dimension R |
0.3 mm |
