| Material | High Carbon Chromium Bearing Steel |
| Type | Standard type (with cage) |
| Country of Origin | Japan |
| Type of Product | Shell Needle Bearing TA (Metric) |
Material |
High Carbon Chromium Bearing Steel |
Type |
Standard type (with cage) |
Country of Origin |
Japan |
Type of Product |
Shell Needle Bearing TA (Metric) |
Model No |
TA3720Z |
Rolling element material |
High carbon chromium bearing steel |
Load direction |
Radial |
No. of Track Trains |
Single row |
Race ring shape |
Needle roller bearing |
Monotaro ID |
38305215 |
Inscribed Circle Diameter Fw (Φmm) |
37 |
Import Country |
Direct Import from Japan |
Outer ring type |
Flat |
JIS grade |
0 |
Shield Shape |
Standard type |
Mass (g) |
64.5 g |
Name of Manufacturer/Packer/Importer |
Nippon Thompson Co., Ltd. |
Outer Diameter D (Φmm) |
47 |
Allowable Rotation Speed (min-1 [rpm]) |
9500 |
Width C (mm) |
20 |
Basic static load rating Co (N) |
45400 |
Basic dynamic load rating C (N) |
27800 |
Combination part no. |
(Inner ring) IRT3220 |
