Ships within 25 days
View
View
View
View
| Material | High Carbon Steel |
| Type | Without inner ring |
| Country of Origin | Japan |
| Type of Product | Needle Bearing With Thrust Ball Bearing Nax |
Material |
High Carbon Steel |
Type |
Without inner ring |
Country of Origin |
Japan |
Type of Product |
Needle Bearing With Thrust Ball Bearing Nax |
Model No |
NAX1023Z |
Rolling element material |
High Carbon Chromium Bearing Steel |
Race ring shape |
Needle Roller Bearing |
Monotaro ID |
38312802 |
Inscribed Circle Diameter Fw (Φmm) |
10 |
Import Country |
Direct Import from Japan |
JIS grade |
0 |
Mass (g) |
40 |
Name of Manufacturer/Packer/Importer |
Nippon Thompson Co., Ltd. |
Basic Dynamic Load Rating (N) |
(Radial) 8230 (Axial) 10000 |
Cover |
With dust cover |
Basic Static Load Rating (N) |
(Radial) 9190 (Axial) 11100 |
Outer Diameter D (Φmm) |
19 |
Allowable Rotation Speed (min-1 [rpm]) |
9500 |
Dimension L (mm) |
23 |
Dimensions H (mm) |
9 |
Dimension d2 (Φmm) |
25 |
