| Weight | 0.163 Kg |
| Bore Type | Cylindrical (Uses Hardened Shaft Raceway) |
| Material | High Carbon Chrome Bearing Steel |
| Country of Origin | India |
Weight |
0.163 Kg |
Bore Type |
Cylindrical (Uses Hardened Shaft Raceway) |
Material |
High Carbon Chrome Bearing Steel |
Country of Origin |
India |
Cage Material |
Steel |
Series |
RNA49 Series |
Type of Product |
Needle Roller Bearing |
Model No |
RNA4910S |
Width (C) |
22 mm |
Bore Diameter (Fw) |
58 mm |
Outside Diameter (D) |
72 mm |
Seal Type |
Open |
Precision |
P0 |
Roller Type |
Needle Roller |
Bearing Type |
Machined Ring Needle Roller Bearing |
Limiting Speed (Oil) |
7,000 RPM |
Limiting Speed (Grease) |
4,700 RPM |
Dynamic Load Rating |
48.0 kN |
Static Load Rating |
80.0 kN |
Name of Manufacturer/Packer/Importer |
Mechanical Solutions |
Internal Clearance |
CN |
Lubrication Groove |
Yes |
Lubrication Hole |
Yes |
Operating Temperature Range |
-20 ºC to 120 ºC |
Minimum Chamfer Radius (rs) |
0.6 mm |
Design |
Machined Outer Ring with Integral Flanges |
Configuration |
Without Inner Ring |
Enclosure |
Open |
