| Model No | 6450 BL005 |
| Type of Product | Data Bus Cable |
| Color | Blue |
| Insulation Material | PP |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Model No |
6450 BL005 |
Type of Product |
Data Bus Cable |
Color |
Blue |
Insulation Material |
PP |
Country of Origin |
United States |
Outer Diameter |
8.23 mm |
Series |
Alpha Essentials |
Conductor Material |
Tinned Copper |
Shield |
Foil/Braid Shield |
Capacitance |
63.96 pF/m |
Length |
30 m |
Attenuation |
10.7 dB/100 ft @ 400 mHz, 3.8 dB/100 ft @ 50 mHz, 5.4 dB/100 ft @ 100 mHz, 7.6 dB/100 ft @ 200 mHz |
Shape Type |
Twinaxial |
Sheath Material |
Polyvinyl Chloride PVC |
Strands |
0.4 mm |
Standard Met |
CE, CSA, UL |
No. of Strands |
7 |
Maximum Operating Temperature |
+75°C |
Minimum Operating Temperature |
-40°C |
Characteristic impedance (Ω) |
78 Ω |
Screened or Unscreened |
Screened |
Conductor Strand Type |
Stranded |
Core Strands |
7/0.4 mm |
Name of Manufacturer/Packer/Importer |
RS Components & Controls (I) Ltd |
Velocity Ratio |
0.65 |
