Ships within 3 days
IP video input
Model No
View
View
View
View
| Type of Product | Network Video Recorder |
| Model No | VIGI NVR1004H |
| Network Protocol | UPnP (Plug and Play), NTP (Network Timing) |
| Outgoing bandwidth | 60 Mbps |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Network Video Recorder |
Model No |
VIGI NVR1004H |
Network Protocol |
UPnP (Plug and Play), NTP (Network Timing) |
Outgoing bandwidth |
60 Mbps |
Incoming bandwidth |
80 Mbps |
Recording Resolution |
8 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
Network Interface |
1, RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface |
USB Interface |
2x USB 2.0 |
Color |
Black |
Operating Temperature |
-10 to 55°C |
Sata |
1 SATA Interface |
Video Compression |
H.265+/H.265/ H.264+/H.264 |
Country of Origin |
India |
Capability |
2-ch @ 8MP, 4-ch @ 4MP |
IP video input |
4-Channel |
Audio Compression |
G.711A/G.711U/G.726 |
Video Output Mode |
HDMI/VGA Simultaneous Output |
Backup Mode |
Regular Backup, Video Clip Backup |
Name of Manufacturer/Packer/Importer |
TP-Link |
Web Browser |
Chrome (57+), Firefox (52+), Edge (91+) |
Storage Humidity |
10%~90% RH Non-Condensing |
External Power Supply |
DC 12 V/1.5 A |
Operating Humidity |
10%~90% RH Non-Condensing |
VGA Output Resolution |
1 Channel, Resolution: 1920x1080/60Hz, 1680x 1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz |
Record Mode |
Manual Recording, Scheduling Recording, Motion Detection Recording |
HDMI Output Resolution |
1 Channel, Resolution: 3840 ×2160/30Hz, 1920 × 1080/60Hz, 1680× 1050/60Hz, 1440 × 900/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz |
Multi-View Display |
1/4 |
Maximum Power Consumption |
4.25 W (Without Disk) |
Playback Mode |
Instant Playback, Regular Playback, Tag Playback, Event Playback |
Playback Function |
Play, Pause, Stop, Fast Forward, Fast Backward, Play By Frame, Full Screen, Video Clip, Export Clip, Digital Zoom, Lock Recording, Audio On/Off |
Package Contains |
VIGI Network Video Recorder, Power Adapter, HDD Screws, Mouse, Rubber Feet, Quick Installation Guide |
Dimensions (L x W X H) (mm) |
246.2x148.2x45 mm |
Storage Temperature |
-40 to 70°C |
