| Model No | PG09 - 20A |
| Type of Product | Powerguard |
| Application | Teaching, Demonstration & Testing of Electrical Energy Consumption of Residential & Commercial Appliances. It can be used in Houses, Offices, Shops, Schools, Laboratories etc. |
| Accuracy | Class 1 |
Model No |
PG09 - 20A |
Type of Product |
Powerguard |
Application |
Teaching, Demonstration & Testing of Electrical Energy Consumption of Residential & Commercial Appliances. It can be used in Houses, Offices, Shops, Schools, Laboratories etc. |
Accuracy |
Class 1 |
Frequency |
45-55 Hz |
Weight |
300 g |
Dimension |
156 x 78 x 48 mm |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
MECO INSTRUMENTS |
Operating Temperature |
-10°C to +55°C |
Apparent Power |
0.026 - 4.800 kVA |
Measurement |
TRMS |
Power Consumption |
Less than 2 W (with backlight) |
Active Power |
0.026 - 4.800 kW @ 240 V AC |
Humidity |
<70% RH |
Rms Current |
0.110 to 20.00 A |
Rms Voltage |
240 V AC (Nominal) (195 V - 265 Vrms) |
Power Factor |
0.026 - 0.120 kW, 0.120 - 4.800 kW |
Reactive Power |
0.026 - 4.800 kVAr |
Time |
Energy Usage: Hours / Minutes |
Parameters Measured |
TRMS Voltage (V), Frequency (Hz), TRMS Current (A), Power Factor (PF), Apparent Power (KVA), Reactive Power (KVAr), Active Power (KW), Energy Consumption (KWh), Energy Usage Time (EUT), Carbon Emission (CO in Kg) |
Active Energy |
000000 - 999999 kWh |
