| Country of Origin | India |
| Operating Environment | 0°C ~ 40°C : <80%RH (No condensation) 40°C ~ 50°C : <70%RH |
| IP Rating | IP54 (Overall protection with cover closed) |
| Type of Product | Solar Insulation Tester |
Country of Origin |
India |
Operating Environment |
0°C ~ 40°C : <80%RH (No condensation) 40°C ~ 50°C : <70%RH |
IP Rating |
IP54 (Overall protection with cover closed) |
Type of Product |
Solar Insulation Tester |
Operating Altitude |
≤2000 m |
Pollution degree |
2 |
Model No |
PRO DIT-960PV |
Name of Manufacturer/Packer/Importer |
Rameshtha Enterprises |
Storage Environment |
-20°C ~ 60°C : <75% (No condensation) |
Regulatory Compliance and Certification |
CE EN 61010-1; EN IEC 61010-2-034; EN 61557-1, -2. |
Drop Proof |
1 m |
Intended Use |
Indoor use |
Rated Voltage |
125V, 250 V, 500 V, 1000 V |
Output Short-Circuit Current |
<1.5mA |
Measurement Category |
CAT II 1000 V, CAT III 600 V |
Output Voltage Accuracy |
+(0%~20%) |
Testing Range of Insulation Resistance |
0.125MΩ~4000MΩ |
