| Type of Product | Thermal Relay |
| Type | 2E Type |
| Model No | TK-E2 9A |
| Auxiliary Contacts | 1A1B(1NO1NC) |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Thermal Relay |
Type |
2E Type |
Model No |
TK-E2 9A |
Auxiliary Contacts |
1A1B(1NO1NC) |
Ambient Temperature |
Compensation: Yes |
Power Consumption (VA) |
3.8/pole |
Rated Operating Current (A) |
Auxiliary Circuit Rating<br> AC-15 (coil load): 3 (AC 24 V), 2.5 (AC 100-120 V), 2 (AC 200-240 V), 1 (AC 380-440 V), 0.6 (AC 500-600 V)<br> DC-13 (coil load): 1.1 (DC 24 V), 0.28 (DC 100-120 V), 0.14 (DC 200-240 V), - (DC 380-440 V), - (DC 500-600 V) |
Monotaro ID |
50306986 |
Width (mm) |
54 |
Length (mm) |
78.5 |
Thickness (mm) |
97 |
Mass (Kg) |
250 g |
Frame |
E2 Type |
Heat Element Rating (A) |
9 |
Import Country |
Direct Import from Japan |
Temperature Compensation |
Included |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Type of Resetting |
Manual |
Structure |
For electromagnetic switch |
Rated Frequency (Hz) |
50-60 |
Rated Impulse Withstand Voltage (kV) |
6(JIS, IEC) |
Mechanism |
Manual trip: Yes |
Rated Insulation Voltage (V) |
690(JIS, IEC) |
Specification Class |
[Electromagnetic contactor combination type] SC-E1, E2, E2S, Trip class: 10A (JIS, IEC), Applicable electromagnetic contactors: SC-E02, SC-E03, SC-E04, SC-E05 (non-reversible type) |
