| Type of Product | Thermal Relay |
| Type | 2E Type |
| Model No | TK-N5 18A |
| Auxiliary Contacts | 1A1B |
Type of Product |
Thermal Relay |
Type |
2E Type |
Model No |
TK-N5 18A |
Auxiliary Contacts |
1A1B |
Power Consumption (VA) |
6.6/pole |
Rated Operating Current (A) |
Auxiliary Circuit Rating<br> AC-15 (coil load): 3 (AC 24 V), 2.5 (AC 100-120 V), 2 (AC 200-240 V), 1 (AC 380-440 V), 0.6 (AC 500-600 V)<br> DC-13 (coil load): 1.1 (DC 24 V), 0.28 (DC 100-120 V), 0.14 (DC 200-240 V), - (DC 380-440 V), - (DC 500-600 V) |
Monotaro ID |
50307957 |
Width (mm) |
78.5 |
Length (mm) |
78.599999999999994 |
Thickness (mm) |
102.5 |
Mass (Kg) |
270 g |
Frame |
N5 Type |
Import Country |
Direct Import from Japan |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Type of Resetting |
Manual |
Structure |
For electromagnetic switch |
Rated Frequency (Hz) |
50-60 |
Mechanism |
Manual trip: Yes |
Rated Insulation Voltage (V) |
690 |
Specification Class |
Trip class: 10A |
Current (A) (50/60Hz) |
[4P: AC200V, 50Hz] Standard efficiency motor [IE1]: 23.8 (le), Premium efficiency motor [IE3]: 21 (le), [4P: AC400V, 50Hz] Standard efficiency motor [IE1]: 21 (le), Premium efficiency motor [IE3]: 20 (le) [Fuji low-voltage three-phase motor full load current (reference value)] |
Operating Patterns |
Standard Type |
Capacity |
[4P: AC200V-50Hz] 5.5(P), [4P: AC400V-50Hz] 11(P) [Fuji low-voltage three-phase motor full load current (reference value)] kW |
Cord Type |
Rating: B600/R300 |
