Ships within 25 days
View
View
View
View
| Type of Product | Thermal Relay |
| Type | Standard Type |
| Model No | TR-N5L 65A |
| Auxiliary Contacts | 1A1B |
Type of Product |
Thermal Relay |
Type |
Standard Type |
Model No |
TR-N5L 65A |
Auxiliary Contacts |
1A1B |
Power Consumption (VA) |
6.6/pole |
Rated Operating Current (A) |
Auxiliary Circuit Rating<br> AC-15 (coil load): 3 (AC 24 V), 2.5 (AC 100-120 V), 2 (AC 200-240 V), 1 (AC 380-440 V), 0.6 (AC 500-600 V)<br> DC-13 (coil load): 1.1 (DC 24 V), 0.28 (DC 100-120 V), 0.14 (DC 200-240 V), - (DC 380-440 V), - (DC 500-600 V) |
Monotaro ID |
50313182 |
Number of Heat Elements |
2 |
Width (mm) |
149 |
Length (mm) |
103 |
Thickness (mm) |
79 |
Mass (Kg) |
630 g |
Frame |
N5 Type |
Heat Element Rating (A) |
65 |
Import Country |
Direct Import from Japan |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Type of Resetting |
Manual |
Structure |
For electromagnetic switch |
Rated Frequency (Hz) |
50-60 |
Rated Impulse Withstand Voltage (kV) |
6 |
Mechanism |
Manual trip: Yes |
Rated Insulation Voltage (V) |
690 |
Specification Class |
Trip class: 20 |
Operating Patterns |
Tardive form |
