| Type | Groove type / terminal type (groove width: 5.2 mm) |
| Type of Product | Photo Micro Sensor |
| Voltage | Collector-emitter: 30, Emitter-collector: 5 V |
| Connection Type | Printed Circuit Board Terminal |
Type |
Groove type / terminal type (groove width: 5.2 mm) |
Type of Product |
Photo Micro Sensor |
Voltage |
Collector-emitter: 30, Emitter-collector: 5 V |
Connection Type |
Printed Circuit Board Terminal |
Model No |
EE-SX1035 |
Wavelength |
TYP.850 nm (peak spectral sensitivity wavelength) |
No. Of Pin |
4 |
Mass (g) |
0.7 |
Case Material |
Polycarbonate |
Detection Method |
Transmission type |
Monotaro ID |
46482931 |
Detection Distance (mm) |
5.2 |
Country of Origin |
CHINA |
Import Country |
Direct Import from Japan |
Outer Dimensions, Length L x Width W x Height H (mm) |
12.6x6.3x9.9 |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Current (mA) |
Light: 0.5 (Typ.), Dark: 2x10¯⁶ (Typ.), 2x10¯⁴ (Max.) |
Specifications |
Reverse voltage (V): 4 |
Temperature (℃) |
260 (soldering) |
