| Type | Thin Connector / Cord Lead-Out Type (Dc Light) Photomicrosensor |
| Shape | R Type |
| Output | NPN |
| Material | (Emitter/Receiver Part) Polycarbonate |
Type |
Thin Connector / Cord Lead-Out Type (Dc Light) Photomicrosensor |
Shape |
R Type |
Output |
NPN |
Material |
(Emitter/Receiver Part) Polycarbonate |
Type of Product |
Photo / Micro Sensor |
Light Source |
Gaas Infrared Light Emitting Diode |
Protection Class |
IP50 Iec60529 Standard |
Control Output |
NPN Open Collector, Output 5 To 24 Vdc, 100 mA Or Less, Residual Voltage 0.8 V Or Less (At 100 mA Load Current), Residual Voltage 0.4 V Or Less (At 40 mA Load Current), Off Current (Leakage Current) 0.5 mA Or Less |
Connection Type |
Cord Drawer Type |
Model No |
EE-SX677-WR 1M |
Mass (g) |
Approximately 16.9 (Packaged) |
Case Material |
Polybutylene Terephthalate (PBT) |
Standard Sensing Object (mm) |
2 x 0.8 or more Opaque Body |
Detection Method |
Transmission Type (Groove Type) |
Monotaro ID |
39061294 |
Detection Distance (mm) |
5 (Groove Width) |
Country of Origin |
China |
Import Country |
Direct Import from Japan |
Detection Distance |
Groove Width: 5 mm |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Power Supply Voltage (V) |
DC 5 To 24 ±10%, Ripple (Pp) 10% Or Less |
