Ships within 19 days
Model No
View
View
View
View
| Type | Oilproof type |
| Output | PNP |
| Series | E3Z Series |
| Type of Product | Compact Amplifier Built-In Photoelectric Sensor |
Type |
Oilproof type |
Output |
PNP |
Series |
E3Z Series |
Type of Product |
Compact Amplifier Built-In Photoelectric Sensor |
Power Supply Voltage |
DC 12-24 V ± 10% Ripple (pp) 10% or less |
Protection Class |
IEC standard IP67 |
Cable Length |
2 m |
Control Output |
Load power supply voltage DC26.4V or less, load current 100mA or less (residual voltage: load current less than 10mA/1V or less, load current 10-100mA/2V or less), open collector output type (varies depending on NPN/PNP output type), light-ON/light-OFF switch type |
Connection Type |
Cord drawer type |
Model No |
E3Z-D81K 2M |
Cable Length (m) |
2 |
Mass (g) |
Approx. 65 (packed) |
Case Material |
Polybutylene terephthalate |
Detection Method |
Diffuse Reflection Type |
Current Consumption (mA) |
30 or less |
Ambient Humidity (% RH) |
Operating: 35 to 85, Storage: 35 to 95 (with no icing or condensation) |
Monotaro ID |
39052876 |
Head Shape |
Square |
Detection Distance (mm) |
100 (White drawing paper 100 x 100) |
Applicable Standard |
RoHS compliant / CE |
Country of Origin |
China |
Import Country |
Direct Import from Japan |
Included Components |
Instruction manual Note: Reflector and mounting brackets are sold separately. |
With or Without Indication Lamp |
Included |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
Operating: -25 to 55, Storage: -40 to 70 (with no icing or condensation) |
Insulation Resistance (MOhm) |
20 Or More (At 500 VDC) |
