Ships within 19 days
Model No
View
View
View
View
| Type | Built-In Amplifier |
| Output | PNP |
| Type of Product | Photoelectric Sensor with Built-in Compact Amplifier |
| Power Supply Voltage | DC12-24 ± 10% Ripple (pp) 10% or less |
Type |
Built-In Amplifier |
Output |
PNP |
Type of Product |
Photoelectric Sensor with Built-in Compact Amplifier |
Power Supply Voltage |
DC12-24 ± 10% Ripple (pp) 10% or less |
Light Source |
Red light emitting diode |
Protection Class |
IEC standard IP67 |
Control Output |
DC26.4V or less, load current 100mA or less (residual voltage 1V or less), open collector output type (varies depending on NPN/PNP output type), light-ON/light-OFF switch type |
Connection Type |
M8 Connector Type |
Model No |
E3Z-LS81-M3J 0.3M |
Cable Length (m) |
0.3 |
Mass (g) |
Approx. 30 (packed) |
Case Material |
Polybutylene terephthalate |
Detection Method |
Distance setting type |
Monotaro ID |
39053341 |
Head Shape |
Square |
Detection Distance (mm) |
20 to 40 (BGS min setting), 20 to 200 (BGS max setting), 40 to received light intensity threshold value (FGS min setting), 200 to received light intensity threshold value (FGS max setting) |
Country of Origin |
China |
Import Country |
Direct Import from Japan |
Withstand Voltage |
AC1000V 50/60Hz 1min |
Included Components |
Instruction manual Note: Mounting hardware is sold separately. |
With or Without Indication Lamp |
Included |
Detection Distance |
20 to set distance (white paper, black paper 100x100) FGS set distance to 200 or more (white paper 100x100), set distance to 160 or more (black paper 100x100) |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
