| Shape | L-shaped mounting type |
| Material | Light-emitting and receiving parts: Polyphenylene sulfide (PPS) |
| Protection Circuit | Included |
| Type of Product | Photo Micro Sensor |
Shape |
L-shaped mounting type |
Material |
Light-emitting and receiving parts: Polyphenylene sulfide (PPS) |
Protection Circuit |
Included |
Type of Product |
Photo Micro Sensor |
Power Supply Voltage |
DC 24 V ±10% ripple (p- |
Operation Mode |
ON during shading |
Connection Type |
Connector |
Model No |
EE-SX3173-P3-Z |
Mass (g) |
About 1.5 |
Case Material |
Polybutylene terephthalate (PBT) |
Ambient Illumination to Use (Lx) |
1000 or less |
Detection Method |
Transmission type (groove type) |
Current Consumption (mA) |
15 or less |
Monotaro ID |
84587434 |
Detection Distance (mm) |
5 (groove width) |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Storage Temperature |
-30 to 80℃ |
Slit Dimensions (mm) |
Light-emitting side: 1.4 x 1.4, light-receiving side: 1.4 x 0.5 (vertical x horizontal) |
Structure |
Reference structure |
Specifications |
Screw mounting size: M3 |
