| Type | Groove type / terminal type with screw mounting tabs (groove width: 3.4 mm) |
| Material | Material: Polycarbonate |
| Type of Product | Photo Micro Sensor |
| Connection Type | Cord soldering terminals |
Type |
Groove type / terminal type with screw mounting tabs (groove width: 3.4 mm) |
Material |
Material: Polycarbonate |
Type of Product |
Photo Micro Sensor |
Connection Type |
Cord soldering terminals |
Model No |
EE-SV3-GS |
Mass (g) |
1 |
Detection Method |
Transmission type (groove type) |
Monotaro ID |
46482913 |
Sensor Shape |
T type |
Detection Distance (mm) |
3.4 (groove width) |
Country of Origin |
JAPAN |
Import Country |
Direct Import from Japan |
Output Format |
Phototransistor |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Storage Temperature |
-30 to 100℃ |
Slit Dimensions (mm) |
Both light-emitting and light-receiving sides: 0.5 x 2.1 (length x width) |
Folded back duration(seconds) |
4(μs) |
Moving-up Duration Time (μs) |
4 |
Operating Temperature (c) |
-25 to 85℃ |
Cap Material |
Polycarbonate |
