| Type | Small |
| Type of Product | Small Head Amplifier Photoelectric Sensor |
| Protection Class | IEC standard IP66 (* Both are limited to indoor use) |
| Connection Type | Cord drawer type |
Type |
Small |
Type of Product |
Small Head Amplifier Photoelectric Sensor |
Protection Class |
IEC standard IP66 (* Both are limited to indoor use) |
Connection Type |
Cord drawer type |
Lens Material |
Polycarbonate |
Model No |
E3C-2 2M |
Cable Length (m) |
2 |
Mass (g) |
Approx. 120 (packed) |
Case Material |
Zinc die casting |
Standard Sensing Object (mm) |
Opaque body with Φ8 or more |
Ambient Illumination to Use (Lx) |
Light receiving surface illumination Incandescent lamp: 3000 or less, Sunlight: 10000 or less |
Detection Method |
Transmission type |
Ambient Humidity (% RH) |
Operating: 35 to 85, Storage: 35 to 95 (with no icing or condensation) |
Monotaro ID |
39049857 |
Head Shape |
Square |
Detection Distance (mm) |
2000 |
Positioning Angle |
Emitter / receiver: 3 to 15° each |
Country of Origin |
JAPAN |
Import Country |
Direct Import from Japan |
Included Components |
Mounting bracket (with screws), instruction manual |
Vibration Resistance (Destruction) |
10 to 55 Hz, 1.5 mm double amplitude, 2 hours each in X, Y, and Z directions |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
During operation and storage: -25 to 70 (but do not allow freezing or condensation) |
Insulation Resistance (MOhm) |
20 Or More (At 500 VDC) |
Name |
Receiver + Emitter |
