Omron Transparent Body Detection Photoelectric Sensor 20 mΩ or More At 500 VDC, E3ZM-B66T-C

Name: Omron Transparent Body Detection Photoelectric Sensor 20 mΩ or More At 500 VDC, E3ZM-B66T-C
Brand: Omron
SKU: IND.PHO.438887110
Price: 25959 INR
Availability: InStock

Visit the Omron Store

EMI starts at ₹2306/month. No Cost EMI available.

Available offers

Get Flat 10% off on your First Orders above ₹3,000

View

Get Flat 10% off on your First Order above ₹3,000

View

Get Flat 10% off on your First Order above ₹3,000

View

Get Flat 3% off on First Order above ₹3,000

View

Features

Type	Built-in amplifier
Protection Circuit	Power supply reverse connection protection, load short-circuit protection, mutual interference prevention function, output reverse connection protection
Type of Product	Transparent Body Detection Photoelectric Sensor
Power Supply Voltage	DC 10-30 V including ripple (pp) 10%

More Omron Photoelectric Sensors products More Photoelectric Sensors products

100% Original Products

Secure Payments

100% Buyer Protection

Top Brands

specifications

Type	Built-in amplifier
Protection Circuit	Power supply reverse connection protection, load short-circuit protection, mutual interference prevention function, output reverse connection protection
Type of Product	Transparent Body Detection Photoelectric Sensor
Power Supply Voltage	DC 10-30 V including ripple (pp) 10%
Protection Class	IEC60529 standard IP67 / DIN40050-9 standard IP69K
Control Output	Load power supply voltage 30 V DC or less, load current 100 mA or less (residual voltage 2 V or less), open collector output
Connection Type	M8 connector type
Lens Material	Methacrylic resin
Model No	E3ZM-B66T-C
Mass (g)	Approx. 20 (packed)
Case Material	SUS316L
Standard Sensing Object (mm)	Transparent round PET bottle 500m (l Φ65)
Ambient Illumination to Use (Lx)	Light receiving surface illumination Incandescent lamp: 3000 or less, Sunlight: 10000 or less
Detection Method	RetroReflective Type (with MSR function)
Monotaro ID	46556395
Head Shape	Square
Detection Distance (mm)	100 to 500 (when using E39-RP1)
Country of Origin	JAPAN
Cable Material	Vinyl chloride
Import Country	Direct Import from Japan
Included Components	Instruction manual, dedicated reflector
Sensitivity Adjustments	Single turn volume
Name of Manufacturer/Packer/Importer	Omron Corporation
Operation Ambient Temperature (°C)	Operating: -25 to 55, Storage: -40 to 70 (with no icing or condensation)
Insulation Resistance (MOhm)	20 Or More (At 500 VDC)
