| Type | Built-In Amplifier |
| Power Supply | DC 12–24 ± 10%, Ripple (pp) 10% or less |
| Protection Circuit | Power supply / control output reverse connection protection, load short-circuit protection |
| Series | E3T Series |
Type |
Built-In Amplifier |
Power Supply |
DC 12–24 ± 10%, Ripple (pp) 10% or less |
Protection Circuit |
Power supply / control output reverse connection protection, load short-circuit protection |
Series |
E3T Series |
Type of Product |
Ultra-Compact, Ultra-Thin Photoelectric Sensor (M3 mounting Type) |
Power Supply Voltage |
DC 12-24 V ± 10% Ripple (pp) 10% or less |
Protection Class |
IEC60529 standard IP67 |
Control Output |
Load power supply voltage 26.4 V DC or less, load current 50mA or less (residual voltage 2V or less (load current 10 to 50mA), 1V or less (load current less than 10mA)), open collector output type |
Connection Type |
Cord drawer type |
Model No |
E3T-ST21MF2M |
Cable Length (m) |
2 |
Case Material |
Polybutylene terephthalate |
Standard Sensing Object (mm) |
Opaque body with Φ2 or more |
Detection Method |
Transparent Type |
Current Consumption (mA) |
30 or less (Emitter: 10 or less, Receiver: 20 or less) |
Monotaro ID |
66471606 |
Head Shape |
Square |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Included Components |
Instruction manual, mounting set screws (side view: M2 x 14, flat: M2 x 8), nuts |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
Operating: -25 to 55, Storage: -40 to 70 (with no icing or condensation) |
Insulation Resistance (MOhm) |
20 or more (DC 500 V) |
Locator Material |
Opaque body with Φ2 mm or more |
