| Type | Groove type/connector type |
| Shape | Side mounting type |
| Material | Light-emitting and receiving parts: Polyphenylene sulfide (PPS) |
| Type of Product | Photo Micro Sensor |
Type |
Groove type/connector type |
Shape |
Side mounting type |
Material |
Light-emitting and receiving parts: Polyphenylene sulfide (PPS) |
Type of Product |
Photo Micro Sensor |
Power Supply Voltage |
DC 13.2 V |
Connection Type |
Connector |
Model No |
EE-SX3162-P1-Z |
Mass (g) |
About 1.2 |
Case Material |
Polybutylene terephthalate (PBT) |
Detection Method |
Transmission type |
Current Consumption (mA) |
25 or less |
Monotaro ID |
66550837 |
Detection Distance (mm) |
5 |
Country of Origin |
JAPAN |
Import Country |
Direct Import from Japan |
Outer Dimensions, Length L x Width W x Height H (mm) |
13x16x14 |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Output Current (mA) |
16 |
Output Voltage (V) |
13.2, Low Level: 0.3 Or Less (Iout=16Ma) (Dark-On Type: Dark, Light-On Type: Light), High Level: Vccx0.9 Or More (Vout=Vcc, Rl=47Kω) (Dark-On Type: Light, Light-On Type: Dark) |
