| Type | M2 mounting type |
| Material | Display window: Modified polyarylate |
| Type of Product | Ultra-Thin Amplifier Built-In Photoelectric Sensor |
| Power Supply Voltage | DC 12-24 V ± 10% Ripple (pp) 10% or less |
Type |
M2 mounting type |
Material |
Display window: Modified polyarylate |
Type of Product |
Ultra-Thin Amplifier Built-In Photoelectric Sensor |
Power Supply Voltage |
DC 12-24 V ± 10% Ripple (pp) 10% or less |
Protection Class |
IEC60529 standard IP67 |
Control Output |
Load power supply voltage 26.4VDC or less, load current 50mA or less, (residual voltage 2V or less (load current 10-50mA) 1V or less (load current less than 10mA)) Open collector output type |
Connection Type |
Cord drawer type (standard cord length 2m) |
Model No |
E3T-ST33-5M |
Cable Length (m) |
5 |
Mass (g) |
Approx. 40 (packed) |
Case Material |
Polybutylene terephthalate |
Detection Method |
Through-beam type |
Current Consumption (mA) |
30 or less (emitter 10 or less, receiver 20 or less) |
Monotaro ID |
46436722 |
Head Shape |
Square side view |
Detection Distance (mm) |
2000 |
Applicable Standard |
CE marking, ISO13849-1 (PLc, cat1) |
Country of Origin |
JAPAN |
Import Country |
Direct Import from Japan |
Included Components |
Instruction manual, mounting set screws (side view: M2x14, flat: M2x8), nuts |
Operating Temperature Range |
Operating: -25 to 55℃, Storage: -40 to 70℃ (but do not allow freezing or condensation) |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Insulation Resistance (MOhm) |
20 or more (DC 500 V) |
