| Type | Robot (flex-resistant) cord type, M3 mounting type |
| Output | NPN output |
| Material | Display window: Modified polyarylate |
| Type of Product | Ultra-Thin Amplifier Built-In Photoelectric Sensor |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type |
Robot (flex-resistant) cord type, M3 mounting type |
Output |
NPN output |
Material |
Display window: Modified polyarylate |
Type of Product |
Ultra-Thin Amplifier Built-In Photoelectric Sensor |
Power Supply Voltage |
DC 12-24 V ± 10% Ripple (pp) 10% or less |
Protection Class |
IEC60529 standard IP67 |
Control Output |
Load power supply voltage 26.4VDC or less, load current 50mA or less (residual voltage 2V or less (load current 10-50mA), 1V or less (load current less than 10mA)) Open collector output type |
Connection Type |
Cord drawer type |
Model No |
E3T-FD11MR-2M |
Cable Length (m) |
2 |
Mass (g) |
Approx. 20 (packed) |
Case Material |
Polybutylene terephthalate |
Detection Method |
Diffuse reflection type |
Current Consumption (mA) |
20 or less |
Monotaro ID |
46434552 |
Head Shape |
Square flat |
Detection Distance (mm) |
5-30 (white paper 50x50) |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Included Components |
Instruction manual, mounting kit, screws (M2x8), nuts |
Operating Temperature Range |
Operating: -25 to 55℃, Storage: -40 to 70℃ (but do not allow freezing or condensation) |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Specifications |
●Amplifier type: Built-in amplifier type |
