| Type | Built-in amplifier |
| Shape | Square |
| Output | NPN |
| Type of Product | Stainless Steel Case Small Photoelectric Sensor |
Type |
Built-in amplifier |
Shape |
Square |
Output |
NPN |
Type of Product |
Stainless Steel Case Small Photoelectric Sensor |
Power Supply Voltage |
DC 10-30 V including ripple (pp) 10% |
Protection Class |
IEC standard IP67, DIN40050-9 standard IP69K |
Control Output |
Load power supply voltage 30 V DC or less, load current 100 mA or less (residual voltage 2 V or less), open collector output type, ON when light is ON / ON when light is switched |
Connection Type |
Cord drawer type |
Model No |
E3ZM-T63-5M |
Cable Length (m) |
5 |
Case Material |
SUS316L |
Standard Sensing Object (mm) |
Opaque body with Φ2 or more |
Detection Method |
Through-beam type |
Current Consumption (mA) |
40 or less (Emitter 20 or less, Receiver 20 or less) |
Ambient Humidity (% RH) |
Operating: 35 to 85, Storage: 35 to 95 (with no icing or condensation) |
Monotaro ID |
46451867 |
Country of Origin |
JAPAN |
Import Country |
Direct Import from Japan |
Included Components |
Instruction manual |
Set Contents |
Floodlight + receiver |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
Operating: -25 to 55, Storage: -40 to 70 (with no icing or condensation) |
Insulation Resistance (MOhm) |
20 Or More (At 500 VDC) |
