| Type | Groove Type (L Type) |
| Shape | L type |
| Output | NPN |
| Material | Emitter/receiver: Polycarbonate (PC) |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type |
Groove Type (L Type) |
Shape |
L type |
Output |
NPN |
Material |
Emitter/receiver: Polycarbonate (PC) |
Protection Circuit |
Load Short Protection |
Type of Product |
Photo/Micro Sensor |
Power Supply Voltage |
DC5 to 24 ± 10% Ripple (pp) 10% or less |
Protection Class |
IEC60529 standard IP50 |
Control Output |
Load Power Supply Voltage: Dc 5 To 24 V, Load Current: 50 Ma Or Less, Off Current: 0.5 Ma Or Less, Residual Voltage: 0.7 V Or Less (At Load Current Of 50 Ma), 0.4 V Or Less (At Load Current Of 5 Ma) |
Connection Type |
Robot Cord Pull-Out Type |
Model No |
EE-SX951-R1M |
Cable Length (m) |
1 |
Mass (g) |
Approx. 15 (packed) |
Case Material |
Polybutylene terephthalate (PBT) |
Standard Sensing Object (mm) |
Opaque body of 1.8x0.8 or more |
Cover Material |
Polybutylene terephthalate (PBT) |
Detection Method |
Transmission Type (Groove Type) |
Current Consumption (mA) |
15 or less |
Ambient Humidity (% RH) |
Operating: 5 to 85 Storage: 5 to 95 (No Frost Or Condensation) |
Monotaro ID |
66482553 |
Detection Distance (mm) |
5 (groove width) |
Country of Origin |
JAPAN |
Vibration Resistance (Destruction) |
10 to 2000 Hz (Peak Acceleration 150M/S2 ) Single Amplitude: 0.75 mm X, Y, Z Directions Each 2.5H (15Min Cycle, 10 Cycles) |
Detection Distance |
Groove width: 5 mm |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Category |
Photoelectric Sensors |
