| Type | Thin connector / cord lead-out type (DC light) photomicrosensor |
| Protection Circuit | Load Short Protection |
| Type of Product | Photo Micro Sensor Groove Type Connector |
| Response Frequency (Hz) | 1k or more (average value is 3k) |
Type |
Thin connector / cord lead-out type (DC light) photomicrosensor |
Protection Circuit |
Load Short Protection |
Type of Product |
Photo Micro Sensor Groove Type Connector |
Response Frequency (Hz) |
1k or more (average value is 3k) |
Power Supply Voltage |
DC 5-24 V ± 10%, ripple (pp) 10% or less |
Protection Class |
IEC60529 standard IP50 |
Operation Mode |
Dark-ON/Light-ON (selectable) |
Control Output |
PNP open collector, output 5 to 24 V DC, 50 mA or less, residual voltage 1.3 V or less (at load current 50 mA), off current (leakage current) 0.5 mA or less |
Connection Type |
Cord drawer type |
Model No |
EE-SX676P-WR-1M |
Mass (g) |
Approximately 16.9 (packaged) |
Case Material |
Polybutylene terephthalate (PBT) |
Emitting Element |
Infrared Led |
Standard Sensing Object (mm) |
2 x 0.8 or more opaque body |
Ambient Illumination to Use (Lx) |
Light receiving surface illuminance / fluorescent lamp: 1000 or less |
Cover Material |
Polycarbonate |
Detection Method |
Transmission type (groove type) |
Current Consumption (mA) |
12 or less |
Ambient Humidity (% RH) |
Operating: 5 to 85, Storage: 5 to 95 (but do not allow condensation) |
Monotaro ID |
46483324 |
Country of Origin |
CHINA |
Import Country |
Direct Import from Japan |
Vibration Resistance (Destruction) |
20 to 2000Hz (peak acceleration 100 m/s² ) Double amplitude 1.5 mm X, Y, Z directions 2h (4min cycle) |
Detection Distance |
Groove width: 5 mm |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Specifications |
●Material (light-emitting and receiving parts): Polycarbonate |
