| Type | Built-in amplifier |
| Shape | Horizontal |
| Output | NPN |
| Type of Product | Photoelectric Sensor with Built-In Amplifier |
Type |
Built-in amplifier |
Shape |
Horizontal |
Output |
NPN |
Type of Product |
Photoelectric Sensor with Built-In Amplifier |
Power Supply Voltage |
DC 10-30 V (including 10% ripple (pp)) |
Protection Class |
IEC standard IP67, NEMA 4X (However, limited to indoor use) |
Control Output |
Load power supply voltage 30 V DC or less, load current 100 mA or less (residual voltage 1 V or less), open collector output type, ON when light is ON / ON when light is switched |
Connection Type |
M12 connector type |
Model No |
E3S-AD18 |
Mass (g) |
Approx. 50 (packed) |
Case Material |
Polybutylene terephthalate |
Detection Method |
Diffuse reflection type |
Monotaro ID |
46434175 |
Head Shape |
Square |
Detection Distance (mm) |
100 (wide field of view) (white paper 100 x 100) |
Country of Origin |
JAPAN |
Import Country |
Direct Import from Japan |
Included Components |
Mounting bracket (with screws), sensitivity adjustment driver, volume cap, connector type close-fitting mounting plate, instruction manual |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Dimensions (H x W x D) (mm) |
21x12.4x40 |
