| Type | Built-in amplifier |
| Output | NPN |
| Protection Circuit | Power supply reverse connection protection, output short circuit protection, output reverse connection protection, mutual interference prevention function |
| Type of Product | Stainless Steel Case Small Photoelectric Sensor |
Type |
Built-in amplifier |
Output |
NPN |
Protection Circuit |
Power supply reverse connection protection, output short circuit protection, output reverse connection protection, mutual interference prevention function |
Type of Product |
Stainless Steel Case Small Photoelectric Sensor |
Power Supply Voltage |
DC 10-30 V including ripple (pp) 10% |
Protection Class |
IEC standard IP67, DIN40050-9 standard IP69K |
Control Output |
Load power supply voltage 30 V DC or less, load current 100 mA or less (residual voltage 2 V or less), open collector output type, light-on ON / light-on ON Code connection switching type |
Connection Type |
Cord drawer type |
Lens Material |
Methacrylic resin |
Model No |
E3ZM-LS64H-5M |
Cable Length (m) |
5 |
Mass (g) |
Approx. 90 (packed) |
Case Material |
SUS316L |
Ambient Illumination to Use (Lx) |
Light receiving surface illumination Incandescent lamp: 3000 or less, Sunlight: 10000 or less |
Detection Method |
BGS Reflective Type (fixed distance) |
Current Consumption (mA) |
25 or less |
Monotaro ID |
46451501 |
Head Shape |
Square |
Detection Distance (mm) |
10 to 200 (white paper 100 x 100) |
Country of Origin |
JAPAN |
Import Country |
Direct Import from Japan |
Vibration Resistance (Destruction) |
10 to 55 Hz, 1.5 mm double amplitude, 2 hours each in X, Y, and Z directions |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
Operating: -25 to 55, Storage: -40 to 70 (with no icing or condensation) |
Insulation Resistance (MOhm) |
20 Or More (At 500 VDC) |
