| Height | 95.5 mm |
| Type of Product | Interface Relay |
| Length | 31 mm |
| Coil Voltage | 24 V DC |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Height |
95.5 mm |
Type of Product |
Interface Relay |
Length |
31 mm |
Coil Voltage |
24 V DC |
Country of Origin |
Italy |
Dimension |
31x86.3x95.5 mm |
No. of Pole |
3 |
Series |
58 Series |
Depth |
86.3 mm |
Terminal Type |
Push In |
Input Current |
40 mA |
Operating Temperature Range |
-40 to +70°C |
Contact Configuration |
3PDT |
Maximum Operating Temperature |
+70°C |
Mounting Type |
DIN Rail |
Minimum Operating Temperature |
-40°C |
Maximum Input Voltage |
400 V AC |
Switching Voltage |
250 V AC to 400 V AC |
Turn Off Time |
(DC) 15 ms, (AC) 5 ms |
Minimum Input Voltage |
250 V AC |
Special Features |
AC Coils or DC Coils, Identification Label, Supply Status Indication & Coil Suppression Module as Standard |
Name of Manufacturer/Packer/Importer |
RS Components & Controls (I) Ltd |
Turn On Time |
(AC) 10 ms, (DC) 10 ms |
Relay Switching Classification |
General Purpose Relay |
Manufacturer Part Number |
58.P3.9.024.0050SMA |
Standards Met |
CE, CSA, CULus, EAC, GOST, IMQ, LIoyd's Register, RINA, VDE |
Operating Cycle |
200000 Cycles |
Load Current Rating |
10 A |
Input Resistance |
600 Ω |
Accessory Type |
Jumper Link |
