| Bowl material | Polycarbonate |
| Model No | F150-01 |
| Type of Product | Air Filter |
| Thread Type | RC |
Bowl material |
Polycarbonate |
Model No |
F150-01 |
Type of Product |
Air Filter |
Thread Type |
RC |
Filtration |
5 μm |
Country of Origin |
Japan |
Pipe Connection Diameter |
1/8 inch |
Suitable Fluid |
Air |
Monotaro ID |
35807712 |
Drain Cock |
Bush Type |
Type of Sign |
Without bracket |
Drain Capacity |
15 cm3 |
Fluid Temperature |
5～60° C (Ambient and Flowing) |
Mass |
0.14 Kg |
Maximum Operating Pressure (MPa) |
0.93 MPa |
Drain Discharge |
Manual Drain |
Overall Length (mm) |
98 mm |
Main Unit Material |
Aluminum Die Casting |
Pressure Resistance |
1.47 MPa |
Accessories Included |
Push-type drain cock |
Filter Drain Outlet |
With drain valve |
Name of Manufacturer/Packer/Importer |
Koganei Corporation |
Pipe Connection Size |
3.17 mm |
Import Country |
Direct Import from Japan |
