| Bowl material | Polycarbonate |
| Model No | F300-03A |
| Type of Product | Air Filter |
| Thread Type | RC |
Bowl material |
Polycarbonate |
Model No |
F300-03A |
Type of Product |
Air Filter |
Thread Type |
RC |
Filtration |
5 μm |
Country of Origin |
Japan |
Pipe Connection Diameter |
3/8 inch |
Suitable Fluid |
Air |
Monotaro ID |
35807791 |
Drain Cock |
Auto Drain Type |
Type of Sign |
Without bracket |
Drain Capacity |
55 cm3 |
Fluid Temperature |
5～60° C (Ambient and Flowing) |
Mass |
0.36 Kg |
Maximum Operating Pressure (MPa) |
0.93 MPa |
Overall Length (mm) |
148.5 mm |
Main Unit Material |
Zinc Die Casting |
Pressure Resistance |
1.47 MPa |
Accessories Included |
Auto drain type drain cock, bowl guard |
Filter Drain Outlet |
With drain valve |
Name of Manufacturer/Packer/Importer |
Koganei Corporation |
Pipe Connection Size |
9.52 mm |
Import Country |
Direct Import from Japan |
