| Model No | F-02 |
| Type of Product | Air Filter Semi-Auto Drain |
| Material | Bracket: Aluminum alloy, Body: Steel |
| Thread Type | PT |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Model No |
F-02 |
Type of Product |
Air Filter Semi-Auto Drain |
Material |
Bracket: Aluminum alloy, Body: Steel |
Thread Type |
PT |
Filtration |
5 μm |
Country of Origin |
Japan |
Pipe Connection Diameter |
PT1/4 |
Suitable Fluid |
Compressed air |
Monotaro ID |
34891622 |
Operating Temperature Range |
5 - 60°C |
Type of Sign |
Bracket |
Maximum Operating Pressure (MPa) |
1 |
Name of Manufacturer/Packer/Importer |
MonotaRO |
Import Country |
Direct Import from Japan |
Drain Port Size (Rc) |
46030 |
Maximum Flow Rate (LPM) |
1750 |
Minimum Working Pressure (MPa) |
0.2 (entrance side) |
Assured Pressure Resistance (MPa) |
1.2 |
Filter Drain Storage Volume (mL) |
80 |
Pressure Gauge Connection Size |
Rc1/8 |
Pressure Setting Range |
0.05~0.85 Mpa (exit side) |
Moisture Removal Rate (%) |
82 |
LID Material |
Polyacetal |
Filter |
Semi-auto drain |
