| Bore Size | Ø 20 mm |
| Type of Product | Pneumatic Mini Cylinder |
| Temperature | -20-70 °C |
| Series | MBL Series |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Bore Size |
Ø 20 mm |
Type of Product |
Pneumatic Mini Cylinder |
Temperature |
-20-70 °C |
Series |
MBL Series |
Operating Pressure |
0.15-1.0 MPa (22-145 Psi) (1.5-10.0 Bar} |
Acting Type |
Double Acting |
Country of Origin |
India |
Proof Pressure |
1.5 Mpa (215 Psi) (15 Bar) |
Speed Range |
30-800 mm/s |
Stroke Size |
25 mm |
Name of Manufacturer/Packer/Importer |
A-Tech Pneumatic Private Limited |
Fluid |
Air (to be filtered by 40 µm filter element) |
Stroke Tolerance |
0-150+1.0° >150+1.5° |
Barrel Material |
Aluminum Barrel |
