| Type of Product | Potentiometer |
| Resistance | 25 kOhms |
| Tolerance | 0.1 |
| Type | Control Potentiometer |
Type of Product |
Potentiometer |
Resistance |
25 kOhms |
Tolerance |
0.1 |
Type |
Control Potentiometer |
Series |
3852 |
Termination Style |
Solder Lug Termination |
Shaft Diameter |
3.18 mm |
Power Rating |
2 W |
Mounting Type |
Panel Mount |
Number of Turns |
1 Turn |
Shaft Type |
Smooth / Slotted |
Shaft Length |
22.2 mm |
No. of Gangs |
1 Gang |
Taper |
Linear |
IP Rating |
IP40 |
Switch Type |
No Switch |
Voltage Rating |
350 VAC |
Name of Manufacturer/Packer/Importer |
Bourns |
Maximum Operating Temperature |
+ 125 C |
Minimum Operating Temperature |
- 1 C |
Ordering ID |
652-3852C-282253AL |
Manufacturer Part Number |
3852C-282-253AL |
RoHS Compliant |
RoHS Compliant By Exemption |
Element Type |
Cermet |
No. of Detents |
Without Detent |
Product |
Potentiometers |
Life Cycle |
20000 Cycle |
